Dell OptiPlex 3280 User Manual

About this task
The following image indicates the location of the memory modules and provides a visual representation of the removal
procedure.
Steps
1. Pry and remove the DIMM door from the system-board shield
2. Using your fingertips, spread apart the securing clips on the memory-module slot until the memory module pops up.
3. Slide and remove the memory module from the memory-module slot.
NOTE: Repeat step 2 and 3 if there are two memory modules.
Installing the memory modules
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the memory module and provides a visual representation of the installation
procedure.
Removing and installing components
27

Dell OptiPlex 3280 Specifications

General

Operating System	Windows 10 Pro
Form Factor	All-in-One
Processor	10th Gen Intel Core i3/i5/i7
Memory	Up to 64GB DDR4
Storage	Up to 1TB SSD
Display	21.5-inch FHD (1920x1080)
Graphics	Integrated Intel UHD Graphics
Ports	USB 2.0, HDMI, DisplayPort, RJ-45, audio jack
Networking	Ethernet LAN 10/100/1000
