CAUTION: Ensure that the processor-cover notch is positioned underneath the alignment post.
3. When the processor is fully seated in the socket, pivot the release-lever down and place it under the tab on the processor
cover.
Next steps
1. Install the heat sink.
2. Install the system fan.
3. Install the system-board shield.
4. Install the back cover
5. Install the cable cover (optional).
6. Install the stand.
7. Follow the procedure in After working inside your computer.
Rear-I/O bracket
Removing the rear-I/O bracket
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the stand.
3. Remove the cable cover (optional).
4. Remove the back cover.
5. Remove the system-board shield.
6. Remove the bottom cover
About this task
The following image indicates the location of the rear-I/O bracket and provides a visual representation of the removal
procedure.
