Dell OptiPlex 3280 User Manual

Steps
1. Remove the screw (M2x2.5) that secures the solid-state drive to the system board.
2. Slide and remove the solid-state drive from the M.2 card slot on the system board.
Installing the M.2 2280 solid-state drive/Intel Optane memory
module
Prerequisites
CAUTION: Solid-state drives are fragile. Exercise care when handling the solid-state drive.
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the solid-state drive and provides a visual representation of the installation
procedure.
Removing and installing components
33

Dell OptiPlex 3280 Specifications

General

Operating System	Windows 10 Pro
Form Factor	All-in-One
Processor	10th Gen Intel Core i3/i5/i7
Memory	Up to 64GB DDR4
Storage	Up to 1TB SSD
Display	21.5-inch FHD (1920x1080)
Graphics	Integrated Intel UHD Graphics
Ports	USB 2.0, HDMI, DisplayPort, RJ-45, audio jack
Networking	Ethernet LAN 10/100/1000
