Dell OptiPlex 5000 Tower - Major Components of Optiplex 5000 Tower

Table 1. Screw list (continued)
Component Screw type Quantity Screw image
SD card reader (optional) #6-32 1
System board #6-32
M2x4
6-32
2
1
8
Major components of OptiPlex 5000 Tower
The following image shows the major components of OptiPlex 5000 Tower.
1.
Side cover 2. 3.5-inch hard-disk drive
3. Slim ODD 4. Heat sink
Removing and installing components 11
