Steps
1. Position the fan duct to align it with the slots on the computer chassis.
2. Press the fan duct until it clicks into place.
Next steps
1. Install the side cover.
2. Follow the procedure in after working inside your computer.
Power-supply unit
Removing the power-supply unit
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the side cover.
3. Remove the fan duct.
NOTE:
Note the routing of all cables as you remove them so that you can route them correctly while you are replacing the
power-supply unit.
About this task
The following images indicate the location of the power-supply unit and provide a visual representation of the removal
procedure.
46
Removing and installing components
