Dell Optiplex-620 - Installing a Hard Drive


5. Lift the drive out of the computer and disconnect the power and hard-drive cables from the drive.

6. Disconnect the power and hard-drive cable from the drive.

Installing a Hard Drive

1. Check the documentation for the drive to verify that it is configured for your computer.

2. Unpack the replacement hard drive, and prepare it for installation.

3. If your replacement hard drive does not have the plastic drive bracket attached, remove the bracket from the existing drive by unsnapping it from the
drive.
NOTICE: Do not pull the drive out of the computer by the drive cables. Doing so may cause damage to cables and the cable connectors.
1
securing tabs (2)
2
hard drive
1
power cable
2
serial ATA data cable
NOTICE: To avoid damage to the drive, do not set it on a hard surface. Instead, set the drive on a surface, such as a foam pad, that will sufficiently
cushion it.
