About Your Computer 35
Removing and Attaching the Computer
Stand
1 To remove the computer stand, perform the following steps:
a Turn the computer over so that the stand is at the top.
b Loosen the thumb screw and lift the stand away (see the following
figures).
c Place the computer in a horizontal position.
KYBD_MOUSE Keyboard and mouse connectors
MICROPROCESSOR Microprocessor connector
MODEM Telephony connector
MONITOR Video connector
NIC_USB Integrated network adapter connector and USB
connectors
PAR_SER1_SER2 Parallel and serial connectors
PCI1, PCI2, PCI3, and
PCI4
PCI expansion card connectors
POWER Main power input connector
PSWD Password jumper
H_RISER Horizontal riser board connector; vertical PCI cards
V_RISER Vertical riser board connector; horizontal PCI cards
SPEAKER Internal speaker
Connector or Socket Description
