Dell OptiPlex GX50 - System Board Components

32 About Your Computer
www.dell.com | support.dell.com
Cable Colors
System Board Components
The following figure shows the principal connectors and components on the
system board.
Hard drive Blue pull tab
Floppy drive Black pull tab
CD drive Orange pull tab
ATA or IDE Gray
Control panel Gray
CD audio Blue
Computer audio Black
