About Your Computer 31
Small Mini-Tower Computer
1 Cover release buttons (2) 8 AC power connector
2 Hard drive 9 Padlock ring
3 Internal speaker 10 Microprocessor and airflow shroud
4 Chassis intrusion switch 11 Power supply
5 System board 12 3.5-inch floppy drive
6 Expansion-card slots 13 CD drive
7 I/O ports and connectors
2
1
3
5
6
4
7
8
9
10
11
12
13
