Small Desktop Computer
1 Cover release buttons (2) 8 AC power connector
2 Hard drive 9 Padlock ring
3 Internal speaker 10 I/O ports and connectors
4 Chassis intrusion switch 11 Heat sink assembly
5 Expansion-card cage 12 System board
6 Power supply 13 3.5-inch floppy drive
7 Expansion-card slots 14 CD drive
2
1
3
5
6
4
7
8
9
10
11
12
13
14
