About your monitor │ 17
Electrical specifications
Model P3424WE
Video input signals • HDMI 2.1/DisplayPort 1.2, 600 mV for each
d
ifferential line, 100 ohm input impedance per
differential pair
• USB-C (with Alternate mode) signal input support
AC input voltage/
fr
equency/current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 2.0 A
(typical)
Inrush current • 120 V: 40 A (Max.) at 0°C (cold start)
• 240 V: 80 A (Max.) at 0°C (cold start)
Power consumption •0.3 W (Off mode)
1
•0.3 W (Standby Mode)
1
• 0.7 W (Networked standby mode)
1
•31.7 W (On mode)
1
•180 W (Max.)
2
•27.24 W (Pon)
3
• 86.54 kWh (TEC)
3
1
As defined in EU 2019/2021 and EU 2019/2013.
2
Max brightness and contrast setting with maximum power loading on all USB
ports.
3
Pon: Power consumption of On mode as defined in Energy Star 8.0 version.
TEC: Total energy consumption in kWh as defined in Energy Star 8.0 version.
