Dell P3424WE - USB 3.2 Gen1 (5 Gbps) Upstream Connector; USB 3.2 Gen1 (5 Gbps) Downstream Connector

24  │  About your monitor
USB 3.2 Gen1 (5 Gbps) upstream connector
Pin number 9-pin side of the connector
1 VCC
2 D-
3 D+
4 GND
5 SSTX-
6 SSTX+
7 GND
8 SSRX-
9 SSRX+
USB 3.2 Gen1 (5 Gbps) downstream connector
Pin number 9-pin side of the connector
1 VCC
2 D-
3 D+
4 GND
5 SSRX-
6 SSRX+
7 GND
8 SSTX-
9 SSTX+
