Dell P3424WE - Connector and Interface Details; Pin Assignments; DisplayPort Connector

About your monitor  │  21
Pin assignments
Pin
number
20-pin side of the
connected signal cable
1 ML3 (n)
2 GND
3 ML3 (p)
4 ML2 (n)
5 GND
6 ML2 (p)
7 ML1 (n)
8 GND
9 ML1 (p)
10 ML0 (n)
11 GND
12 ML0 (p)
13 GND
14 GND
15 AUX (p)
16 GND
17 AUX (n)
18 Hot Plug Detect
19 Re-PWR
20 +3.3 V DP_PWR
DisplayPort connector
