Dell P93F - Solid State Drive; Removing the Primary M.2 Solid-State Drive

Solid State Drive
Removing the primary M.2 Solid-state drive
Prerequisites
NOTE: For computers shipped with M.2 2280 installed in slot 3 and/or M.2 2280 or 2230 Solid-state drive in slot 5.
NOTE: Slot 3 and slot 5 supports PCIe Gen3, Optane, and SATA Solid-state drive.
1. Follow the procedure in before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
About this task
The figure indicates the location of the primary M.2 SSD and provides a visual representation of the removal procedure.
M.2 2280 SSD
M.2 2230 SSD
Removing and installing components
31
