11. Pry the coin-cell battery, located under the system board, from the palmrest while lifting the system board.
NOTE: When replacing the system board, the Type-C bracket on the left side under the system board must be
relocated to the replacement system board.
NOTE: If the Type-C bracket becomes detached from the system board anytime after the system board is removed
from the computer, re-adhere the bracket onto the system board.
12. Remove the system board from the computer.
Installing the system board
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The figure indicates the location of the system board and provides a visual representation of the installation procedure.
