Hardware Installation

Figure 4-1. Installing a PERC S300 Adapter

1 bracket screw 2 PERC S300 Adapter

3 PCI-E slot 4 filler bracket

5 PCI bracket

A5_bk0.book Page 33 Thursday, February 10, 2011 8:34 PM
