Figure 5. PSU status indicator and self-diagnostic button
1 self-diagnostic button 2 PSU status indicator
Table 8. PSU status indicators
Power indicator pattern Condition
Green A valid power source is connected to the PSU and the PSU is operational.
Not lit Power is not connected.
Dell PowerEdge T30 system overview 15
