CAUTION: Do not remove or install the internal cooling fan by holding the fan blades.
Figure 56. Removing the internal cooling fan
1. arrow 2. internal cooling fan
3. internal cooling fan power cable 4. release tab
Next steps
1. Install the internal cooling fan.
2. Follow the procedure listed in the After working inside your system section.
Related links
Safety instructions
Before working inside your system
Removing the cooling shroud
Installing the internal cooling fan
After working inside your system
Installing the internal cooling fan
Prerequisites
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
140
