Next steps
1. Install the palm-rest assembly
2. Install the display assembly.
3. Install the keyboard assembly.
4. Install the smart card reader.
5. Install the LED board.
6. Install the power-button board.
7. Install the system board.
8. Install the heat sink.
9. Install the assembly inner frame.
10. Install the battery.
11. Install the memory modules.
12. Install the wireless card.
13. Install the 2280 solid-state drive or 2230 solid-state drive.
14. Install the base cover.
15. Install the microSD card.
16. Follow the procedure in After working inside your computer.
Palm-rest assembly
Removing the palm-rest assembly
Prerequisites
1. Follow the procedure inBefore working inside your computer.
2. Remove the microSD card.
3. Remove the base cover.
4. Remove the 2280 solid-state drive or 2230 solid-state drive.
5. Remove the memory modules.
6. Remove the battery.
7. Remove the wireless card.
Removing and installing components
95
