Dell Precision 7750 - Installing the Primary Memory Module

2. Slide the memory shield towards the right side of the computer and lift the shield from the memory module.
3. Pry the securing clips from both side of the memory module until the memory module pops up.
4. Remove the memory module from the memory-module slot.
NOTE: Repeat the above steps if there are other memory installed.
Installing the primary memory module
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The figure indicates the location of the primary memory module and provides a visual representation of the installation procedure.
Steps
1. Align the notch on the memory module with the tab on the memory-module slot.
2. Slide the memory module firmly into the slot at an angle and press the memory module down until it clicks into place.
3. Carefully align the two clips on the memory shield with the slots on the computer chassis and insert the clips under the chassis.
42
Demonteren en hermonteren
