5. Remove the keyboard lattice.
6. Remove the keyboard.
About this task
The figure indicates the location of the GPU power cable and provides a visual representation of the removal procedure.
Steps
1. Carefully pry the GPU power cable connector outside the end of the connector head to unlock the GPU power cable connector from
the GPU card.
2. Slightly slide the GPU power cable connector outwards to disconnect the GPU power cable from the GPU card.
3. Repeat the above steps to disconnect the GPU power cable from the system board.
4. Peel the GPU power cable from the computer.
Installing the GPU power cable
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The figure indicates the location of the GPU power cable and provides a visual representation of the installation procedure.
Demonteren en hermonteren
61
