• <Ctrl-F8>: Enters Configuration mode. The Configuration screen will
appear.
• <Ctrl-F9>: While in Configuration mode, returns to the previous
screen with History mode enabled.
• <Ctrl-F10>: While in Configuration mode, returns to the previous
screen with On-Line mode enabled.
• <Ctrl-F11>: Clears the history buffer. If you choose this option, a
warning screen will appear. Press <Enter> to delete the history buffer
or <Escape> to cancel the action. The previous screen will reappear.
3 When finished, press <Ctrl-F10> to exit History mode and return to On-
Line mode.
Serial IQ Module Pinouts
The following table lists the pinouts for the serial IQ module.
DB9-F Pin Host Signal Name Description Signal Flow SRL Signal Name Description
1 DCD - Data Carrier Detect Out of SRL DTR - Data Terminal Ready
2 RXD - Receive Data Out of SRL TXD - Transmit Data
3 TXD - Transmit Data In to SRL RXD - Receive Data
4 DTR - Data Terminal Ready In to SRL DSR - Data Set Ready
5 GND - Signal Ground N/A GND - Signal Ground
6 DSR - Data Set Ready Out of SRL DTR - Data Terminal Ready
7 RTS - Request to Send In to SRL CTS - Clear to Send
8 CTS - Clear to Send Out of SRL RTS - Request to Send
9 N/C - Not Connected N/A N/C - Not Connected
Table C.1: Serial IQ Module Pinouts
