6xxx | Product Overviewxxx
Figure 1.1: Example Server Console Switch Configuration
Number Description Number Description
1 UTP Connection 5 Ethernet
2
Local KVM Connection to
the Server Console Switch
6
Digital Users (computer with Internet
Browser for OBWI or RCS Software
and/or Avocent Management Software
Server [requires the Dell RAK])
3 Remote IP Connection 7
Local Analog Users (OSCAR Interface
and/or Local LCD Tray)
4
Server Console Switch
(2161AD shown)
8 Servers/Target Devices
Table 1.1: Descriptions for Figure 1.1
