66xxx | OBWI Operationxxx
2 Select one of the following methods to load the firmware file: Filesystem,
TFTP, FTP, or HTTP.
NOTE: The Filesystem option is only available on the remote OBWI.
3 If you selected Filesystem, select Browse to specify the location of the
firmware upgrade file.
-or-
If you selected TFTP, enter the Server IP Address and Firmware File
you wish to load.
-or-
If you selected FTP or HTTP, enter the Server IP Address and
Firmware File you wish to load, as well as the User Name and User
Password.
4 Click the Upgrade button.
Saving and Restoring SCS Configurations and User Databases
You may save the switch configuration to a file. The configuration file will
contain information about the managed switch. You may also save the local user
database on the switch. After saving either file, you may also restore a previously
saved configuration file or local user database file to the switch.
To save a managed switch configuration or user database of a managed switch:
1 From the side navigation bar, click Unit View - SCS - Files.
2 Click either the SCS Configuration tab or the User Database tab, then
click the Save tab.
3 Select the file save method: Filesystem, TFTP, FTP, or HTTP PUT.
4 If you selected TFTP, enter the Server IP Address and Firmware Filename
you wish to load.
-or-
If you selected FTP or HTTP, enter the Server IP Address, Username,
User Password, and Firmware Filename you wish to load.
