Installationxxx | xxx31
Number Description
1 Local User
2 ARI Connection
3 UTP Connection
4 ACI Connection (chain icon)
Table 2.3: Descriptions for Figure 2.10
Adding a Tiered Legacy Switch
Figure 2.11 illustrates a tiered legacy switch configuration.
To add a legacy switch (optional):
1 Mount the SCS into your rack. Locate a UTP cable (up to 30 meters) to
connect your switch to the legacy switch.
2 Attach one end of the UTP cabling to the ARI port on your switch.
3 Connect the other end of the UTP cable to a PS/2 SIP.
4 Connect the SIP to the legacy switch according to the switch
manufacturer's recommendations.
5 Repeat steps 1-4 for all the legacy switches you wish to attach to your
switch.
NOTE: The primary SCS supports only one switch per ARI port or USB port. You cannot
tier a switch to a tiered switch.
