Appendix F: Technical Specificationsxxx | xxx128
Target Resolutions
Standard
1024 x 768 @ 60 Hz (preferred)
1280 x 1024 @ 60 Hz (preferred)
1600 x 1200 @ 60 Hz (preferred)
Widescreen
1280 x 800 @ 60 Hz (preferred)
1680 x 1050 @ 60 Hz (preferred)
Supported Cabling 4-pair UTP, 30 meters maximum length
Dimensions
Form Factor 1U or 0U rack mount
Dimensions
1.70 x 17.00 x 9.42 inches (Height x Width x Depth)
(4.32 x 43.18 x 23.93 cm)
Weight (without
cables)
1081AD: 5.98 lb (2.71 kg); 2161AD: 6.16 lb (2.79 kg)
10101 Setup Port
Number 1
Protocol RS-232 serial
Connector 8-pin modular (RJ-45)
Local Port
Number/Type
8 Port
1 VGA - HDD15
4 USB
16 Port
2 VGA - HDD15
8 USB
Network Connection
