34xxx | Installationxxx
5 Repeat steps 3 and 4 for all devices you wish to attach.
Figure 2.12: SCS Configuration With a PEM
Number Description
1 ARI Port
2 UTP
3 PEM
4 SIP
5 Target Device
Table 2.5: Descriptions for Figure 2.12
