56xxx | Local OSCAR User Interfacexxx
To simultaneously upgrade multiple SIPs:
1 Activate the OSCAR interface, click Commands > SIP Status and click one
or more types of SIPs to upgrade.
2 Click Upgrade.
NOTE: When the Enable SIP Auto update option is enabled in the SIP Status dialog
box, SIP firmware is automatically upgraded when the switch firmware is upgraded or
when a new SIP is discovered by the switch after a firmware upgrade. SIP modules
that have already been discovered but which are not attached to the switch during the
firmware upgrade must be upgraded manually.
3 The SIP Upgrade dialog box is displayed. Click OK to initiate the upgrade
and return to the SIP Status dialog box.
To return a SIP to factory default status:
1 Click SIP in the Version dialog box.
2 Select a SIP, then click Decommission.
3 Click OK to restore factory defaults. You will see the SIP go offline briefly
and return.
- or-
Click X or press Escape to cancel the operation.
4 Click X to close the SIP Select dialog box.
