OBWI Operationxxx | xxx69
To configure general network settings:
1 Click the Network tab, then click the General tab to display the SCS
General Network Settings screen.
2 Select one of the following options from the LAN Speed drop-down menu:
Auto-Detect, 10 Mbps Half Duplex, 10 Mbps Full Duplex, 100 Mbps Half
Duplex, or 100 Mbps Full Duplex.
NOTE: You must reboot if you change the Ethernet mode.
3 Select either Enabled or Disabled in the ICMP Ping Reply drop-down
menu.
4 Verify or modify the HTTP or HTTPS ports. The settings will default to
HTTP 80 and HTTPS 443.
5 Click Save.
To configure IPv4 network settings:
1 Click the Network tab, then click the Address tab to display the IPv4
Settings screen.
2 Click the IPv4 button.
3 Click to fill or clear the Enable IPv4 checkbox.
4 Enter the desired information in the Address, Subnet, and Gateway fields.
IPv4 addresses are entered as the xxx.xxx.xxx.xxx dot notation.
5 Select either Enabled or Disabled from the DHCP drop-down menu.
NOTE: If you enable DHCP, any information that you enter in the Address, Subnet, and
Gateway fields will be ignored.
6 Click Save.
To configure IPv6 network settings:
1 Click the IPv6 button.
