Table 31. Display specifications (continued)
Feature Specification
Width 224.3 mm (8.83 inches)
Maximum resolution 1366 x 768 pixels
Active area (X/Y) 344.20 mm x 193.50 mm (13.55 inches x 7.62 inches)
Maximum brightness 200 nits
Operating angle 0° (closed) to 135°
Refresh rate 60 Hz
Minimum viewing angles:
Horizontal +/- 40 degrees
Vertical +10/ -30 degrees
Pixel pitch 0.252 mm
Table 32. Keyboard specifications
Feature Specification
Number of keys: US 101, Brazil 104, UK 102, and Japan 105
Pitch
X:19.05 mm/Y: 18.05 mm
Travel distance
3.3 mm
Table 33. Touchpad specifications
Feature Specification
Active Area:
X-axis 105.00 mm (4.13 inches)
Y-axis 80.00 mm (3.14 inches)
Table 34. Battery specifications
Feature Specification
Type
● 4-cell “smart” lithium ion (47 WHr)
Dimensions:
Height 20.00 mm (0.78 in.)
Width 270.00 mm (10.63 inches)
Depth 37.50 mm (1.47 inches)
Weight 0.25 kg (0.56 lb)
Life span 300 discharge/charge cycles
Voltage 14.80 VDC
Temperature range:
Operating 0°C–35 °C (32°F–95 °F)
Non-Operating –40°C–65 °C (–40°F–149 °F)
Coin-cell battery 3 V CR2032 lithium ion
Table 35. AC Adapter specifications
Feature Specification
Type 65 W (discrete)
Technical specifications 79
