Table 35. AC Adapter specifications (continued)
Feature Specification
Input voltage 100 V AC–240 V AC
Input frequency 50 Hz–60 Hz
Input current (maximum)
65 W 1.70 A
Output current
65 W 3.34 A (continuous)
Rated output voltage 19.5 V DC
Temperature range:
Operating -40°C to 21.1°C (-40°F to 70°F)
Non-Operating –40°C–70 °C (–40°F–158 °F)
Table 36. Physical
Feature Specification
Height: 23.65 mm (0.93 inches)
Width: 380.00 mm (14.96 inches)
Depth: 260.30 mm (10.24 inches)
Weight: 2.29 kg (5.04 lb)
Table 37. Environmental specifications
Feature Specification
Temperature:
Operating 0°C–35 °C (32°F–95 °F)
Storage –40°C–65 °C (–40°F–149 °F)
Relative humidity (maximum):
Operating 10% to 90% (non-condensing)
Storage 0% to 95% (non-condensing)
Altitude (maximum):
Operating
–15.2 m to 30482000 m (–50 to 10,0006560 ft)
0° to 35°C
Non-Operating –15.2 m to 10,668 m (–50 ft to 35,000 ft)
Airborne contaminant level G1 as defined by ISA-S71.04-1985
80 Technical specifications
