8. Remove the WWAN card from the computer.
Installing The Wireless Wide Area Network
(WWAN) Card
1. Slide the Wireless Wide Area Network (WWAN) card into its slot.
2. Connect the antenna cables according to the color code on the WWAN
card.
3. Install the
power button board cable
.
4. Install the
keyboard
.
5. Install the
battery
.
6. Follow the procedures in
After Working Inside Your Computer
.
35
