Steps
1. Remove the six (M2.5x2.5) screws securing the display panel to the hinges.
2. Gently flip the display panel assembly forward, peel back the mylar tape securing the display cable on the rear of the display
panel.
NOTE: Ensure the panel has a clean and smooth surface to rest on to prevent damage.
3. Disconnect the display cable from the display panel assembly and lift the display panel away from the system.
NOTE: Do not remove the metal brackets from the panel.
Installation display panel
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
Disassembly and reassembly 63
