Dell Vostro 3671 - Removing and Installing Components; Recommended Tools and Screw List

Removing and installing components
Recommended tools
The procedures in this document require the following tools:
• Phillips #0 screwdriver
• Phillips #1 screwdriver
• Plastic scribe
NOTE:
The #0 screw driver is for screws 0-1 and the #1 screw driver is for screws 2-4
Screw list and images
Table 2. Vostro 3671screw size list
Component Screw type Quanti
ty
Image Color
Power supply unit
Side cover
I/O bracket
Systemboard
PCIe bracket
#6.32xL6.35
4
2
1
8
1
Black
3.5 Hard drive (Optional)
#6.32UNCx3.6
4
Silver
Optical drive M2x2
2
Black
M.2 SSD card
NGFF card
WLAN card
M2x3.5
1
1
1
Silver
2.5 Hard drive (optional 1 pcs)
2.5 Hard drive (optional 2 pcs)
M3x3.5
2
4
Silver
3
10 Removing and installing components
