Dell Vostro 3671 - Removing and Installing the M.2 PCIe SSD

4. Install the:
a) Front bezel
b) Cover
5. Follow the procedure in After working inside your computer.
Removing the M.2 PCIe Solid State Drive - optional
1. Follow the procedure in Before working inside your computer.
2. Remove the Cover.
3. To remove the Solid State Drive (SSD):
a) Remove the one (M2x3.5) screw that secures the SSD to the system board [1]
b) Slide the SSD from the connector on the system board [2].
Removing and installing components
31
