eZV-440 Version 2.1 Application Guide
Document Edition 2.5
Appendix A: Database Configuration Objects
The following table lists the database objects used to configure the eZV-440 controller.
Programs are prevented from writing to algorithm configurable
MV objects, I/O configurable MV objects and network setting variables.
These include MV110-147 and MV1001-1006. See the eZV-440 controller
2.1 release notes for more information.
Input Configuration Objects
Also see these related sections in the document:
•
Set Up Hardwired Occupancy Input
on page 23
•
Set Up a Hardwired Temperature Sensor
on page 21
•
Set up a Hardwired CO2 Sensor
on page 24
•
Set Up Damper Feedback
on page 25
•
Set Up Other Supporting Inputs
on page 25
SpaceTemp AV1
°C
to average if multiple
InletAirTemp AV5
°C
upstream from local
heating or cooling stages
that supply the air to that
space.
DischargeAirTemp AV6
°C
downstream from any
local heating or cooling
stages that supply the air
DifferentialPressure1 AV11 inH2O
the differential pressure
sensor used to measure
Damper1Feedback AV13 %
Position feedback signal
from a damper.
FanStatus MV7 N/A
Status of the zone supply
fan.
NotUsed_, Off_, On_.
Default = NotUsed_
