Delta Controls eZVP-440 User Manual

eZV-440 Version 2.1 Application Guide
Page 62 of 67
Document Edition 2.5
Object Name
Object
Ref
Default
Units
Description
Options
HeatingDemandLimit
AV163
%
Heating demand limit
Default = 100
OATCoolLockoutSetpoint AV165
°C
Outside air temperature cool
lockout setpoint. Not used by
VAV/VVT systems.
Default = -99
DATLowLimitSetpoint AV166
°C
Discharge air temperature low
limit setpoint Not used by
VAV/VVT systems.
Default = 12
CoolingDemandLimit
AV167
%
Cooling demand limit
Default = 100
CO2OccOnSetpoint
AV182
ppm
CO
2
high limit occupancy setpoint
Default = 900
CO2OccOffSetpoint
AV183
ppm
CO
2
low limit occupancy setpoint
Default = 700
CO2DemandVentSetpoint
AV185
ppm
CO demand ventilation setpoint
Default = 1100
FanMinSpeed AV197
N/A
Minimum supported fan speed
Default = 20 (ECM),
1 (Binary)
FanMaxSpeed AV198
N/A
Maximum supported fan speed
Default = 100 (ECM),
1 (Binary)
CurrentHeatSetpoint
AV800
°C
Current heating setpoint reading
Default = 0
CurrentCoolSetpoint
AV801
°C
Current cooling setpoint reading
Default = 0
ActiveSpaceTempSetpoint AV829
°C
Current active setpoint (reading
either heating or cooling setpoint,
reads space temperature in
deadband)
In manual mode, the active
setpoint will override the current
heating and cooling setpoints.
Default =
Airflow Setpoint AV830
CFM (VAV)
% (VVT)
Current airflow setpoint reading
(VAV)
Damper position at this setpoint
(VVT)
Default = 0
Device Instance/BACnet Address Object
The BACnet address is a unique address given to every controller and device in a Delta network.
In the eZ-440 controller firmware version 2.01, you can set or change the eZV-440 controller’s
BACnet address by writing to the AV97 object (BACnetAddress).
The BACnet address can range from 1 to 4 million+. Since AV objects can only store 6 digits of
the BACnet address, the seventh or millionth digit is stored in the AV97 description field.
When a value is manually written to AV97 object, ORCAview recognizes that the user is trying to
software address the controller and so DNA, if enabled, will automatically turn off. To turn DNA
back on, you need to access the DEV object in ORCAview and select the DNA checkbox.
