Appendix A Accessories|ASDA-A&A+ Series
Revision April 2009 A-7
Power Cables: ASD-CAPW3303, ASD-CAPW3305 (cable for motors with brake)
(for 4.5kW model)
L L1
Item Part No. Straight
mm inch mm inch
1 ASD-CAPW3303 MS 3106-24-11S
3000 ± 10 118 ± 0.4 3100 ± 10 122 ± 0.4
2 ASD-CAPW3305 MS 3106-24-11S
5000 ± 10 197 ± 0.4 5100 ± 10 201 ± 0.4
îš„ Encoder Connectors
Delta Part Number: ASD-CAEN0000
HOUSING: AMP (1-172211-0)
TERMINAL: AMP (170376-3)
Vendor Name Vendor P/N
3M TAIWAN LTD 10120-3000PE
3M TAIWAN LTD 10320-52A0-008
Delta Part Number: ASD-CAEN1000
