Revision April 2009 B-1
Appendix B Molded-case Circuit Breaker, Fuse Current
and EMI Filters
Molded-case Circuit Breaker and Fuse Current Recommended Value
¾ Caution: Please use molded-case circuit breaker and fuse which are recognized by and comply with the UL or
CSA standards.
ASDA-A Series Servo Drive
Model Name Breaker Fuse (Class T)
Operation Mode General General
ASD-A0121LA 5A 5A
ASD-A0221LA 6A 6A
ASD-A0421LA 10A 10A
ASD-A0721LA 10A 20A
ASD-A1021LA 15A 25A
ASD-A1021MA 15A 20A
ASD-A1521LA 20A 40A
ASD-A1521MA 20A 40A
ASD-A2023LA 30A 50A
ASD-A2023MA 30A 50A
ASD-A3023LA 30A 70A
ASD-A3023MA 30A 70A
ASDA-A+ Series Servo Drive
Model Name Breaker Fuse
Operation Mode General General
ASD-A4523-B 50A 120A
ASD-A5523-B 50A 120A
ASD-A7523-B 50A 120A
