Chapter 5 Parameters|VFD-S Series
5-34 Revision August 2008, SE09, SW V2.61
Setting Function Description
d10 PLC Program Running the output will be activated when the PLC program is
running.
d11 PLC Program Step
Completed
the output will be activated for 0.5 sec. when each multi-
step speed is attained.
d12 PLC Program Completed the output will be activated for 0.5 sec. when the PLC
program cycle has completed.
d13 PLC Operation Paused the output will be activated when PLC operation is
paused.
d14
Terminal Count Value
Attained
counter reaches Terminal Count Value.
d15
Preliminary Counter Value
Attained
counter reaches Preliminary Count Value.
d16 AC Motor Drive Ready
d17 FWD Command Indication When AC drive receives the command of forward
running, it will output immediately no matter AC drive is
in the state of run or stop.
d18 REV Command Indication When AC drive receives the command of reverse
running, it will output immediately no matter AC drive is
in the state of run or stop.
