Delta Electronics RTU-EN01

Modbus TCP Remote I/O Communication Module RTU-EN01
DVP-PLC Operation Manual
9
BR# Attribute Content Explanation Default Latched
24 R
ID of the 1st analog
I/O module
ID of the 1st analog I/O module NO
25 R
ID of the 2nd analog
I/O module
ID of the 2nd analog I/O module NO
26 R
ID of the 3rd analog
I/O module
ID of the 3rd analog I/O module NO
27 R
ID of the 4th analog
I/O module
ID of the 4th analog I/O module NO
28 R
ID of the 5th analog
I/O module
ID of the 5th analog I/O module NO
29 R
ID of the 6th analog
I/O module
ID of the 6th analog I/O module NO
30 R
ID of the 7th analog
I/O module
ID of the 7th analog I/O module NO
31 R
ID of the 8th analog
I/O module
ID of the 8th analog I/O module NO
32 ~ 49 Reserved NO
50 R/W RTC settings Settings of the real-time clock NO
51 R/W Year Range: 1970 ~ 2099 YES
52 R/W Week Range: 1 ~ 7 YES
53 R/W Month Range: 1 ~ 12 YES
54 R/W Day Range: 1 ~ 31 YES
55 R/W Hour Range: 0 ~ 23 YES
56 R/W Minute Range: 0 ~ 59 YES
57 R/W Second Range: 0 ~ 59 YES
58 ~ 59 Reserved NO
60 Reserved NO
61 ~ 63 Reserved 0 NO
Symbol “R” refers to ready only; “R/W” refers to read and write.
4.2 Explanations on BR
BR#0: Model Name
Explanations:
1. Model code of RTU-EN01 = H’0600.
2. You can read the model code in the program to see if the extension module exists.
BR#1: Firmware Version
Explanations:
The firmware version of RTU-EN01 is displayed in hex, e.g. H’0100 indicates version V1.00
BR#2: Release Date of the Version
Explanations:
Displaying the data in decimal form. 10,000s digit and 1,000s digit are for “month”; 100s digit and 10s digit are for
“day”. For 1s digit: 0 = morning; 1 = afternoon.
Example: 12191 indicates the version released in the afternoon of December 19.
