Modbus TCP Remote I/O Communication Module RTU-EN01
DVP-PLC Operation Manual
13
RCR# Attribute Content Explanation Default Latched
200 ~ 249 R/W
The 5
th
analog I/O
module
Control register for the 5
th
analog I/O
module
-- NO
250 ~ 299 R/W
The 6
th
analog I/O
module
Control register for the 6
th
analog I/O
module
-- NO
300 ~ 349 R/W
The 7
th
analog I/O
module
Control register for the 7
th
analog I/O
module
-- NO
350 ~ 399 R/W
The 8
th
analog I/O
module
Control register for the 8
th
analog I/O
module
-- NO
Symbol “R” refers to ready only; “R/W” refers to read and write.
RCR#0 ~ #399: Control Register for Right-Side Analog I/O Modules
Explanations:
By reading/writing RCR in RTU-EN01, you are able to store or retrieve the data in the control register (CR) inside
the analog input/output module.
Example: RCR#0 corresponds to CR#0 in the 1
st
analog I/O module. RCR#260 corresponds to CR#10 in the 6
th
analog I/O module. Extension module closest to RTU-EN01 is regarded the 1
st
module.
4.6 Word Devices & Bit Devices for Timers (T)
T# Attribute Register/coil name Explanation Default Latched
0 R/W Timer 0 Timer 0/OFF NO
1 R/W Timer 1 Timer 0/OFF NO
2 R/W Timer 2 Timer 0/OFF NO
3 R/W Timer 3 Timer 0/OFF NO
4 R/W Timer 4 Timer 0/OFF NO
5 R/W Timer 5 Timer 0/OFF NO
6 R/W Timer 6 Timer 0/OFF NO
7 R/W Timer 7 Timer 0/OFF NO
8 R/W Timer 8 Timer 0/OFF NO
9 R/W Timer 9 Timer 0/OFF NO
10 R/W Timer 10 Timer 0/OFF NO
11 R/W Timer 11 Timer 0/OFF NO
12 R/W Timer 12 Timer 0/OFF NO
13 R/W Timer 13 Timer 0/OFF NO
14 R/W Timer 14 Timer 0/OFF NO
15 R/W Timer 15 Timer 0/OFF NO
Symbol “R” refers to ready only; “R/W” refers to read and write.
T#0: Timer 0
Explanations:
When the timer is enabled, it will start to time according to the settings. When the timing reaches the target, the
bit device T0 will be ON. When the bit device is reset, the word device will be reset to 0 as well.
To Next Page
