Delta Electronics RTU-EN01 User Manual

Modbus TCP Remote I/O Communication Module RTU-EN01
DVP-PLC Operation Manual
21
the communication. The IP of the gateway has to be in the same subnet as RTU-EN01. The default
gateway of RTU-EN01 is 192.168.1.1.
3. Timer setting:
For setting up TCP connection idle time, Modbus time-out and minimum delay time for every
communication data. Please refer to the explanations on BR#11, BR#12, and BR#13.
6.4 Network Settings
The first step for all the equipment to connect to the network is to have its own IP (Internet Protocol) address. The
IP address is like a number for every equipment to be identified on the network.
 Setting up static IP of the PC
1. Enter Control Panel → Network Connection → click “Local Area Connection".
2. You will see the “Local Area Connection Status” window. Click “Properties”.
3. Click “Internet Protocol (TCP/IP)”.
