HOW TO ATTACH THE PLANER TO THE STAND
1. CAREFULLY lift the planer on the stand.
of the stand.
3. Use the four remaining M8 carriage head bolts, M8
lock washers and M8 hex nuts to secure the planer to
the stand. Insert bolts down through holes in planer
and stand. Place lock washers then nuts on bolts and
tighten.
Fig. 17.
Insert two M3 Phillips head screws down through holes
serrated hex flange nuts.
Fig. 16
AA
Fig. 17
SS
Fig. 18
FF
HH
HH
