Delta AH Series User Manual

AH Motion Controller – Operation Manual
7-50
_7
 Function Block—DFB_CamCurveUpdate2
After DFB_CamCurve2 is executed, DFB_CamCurveUpdate2 can be used. If you want to modify a rotary cut curve, you
can create a new rotary cut curve by DFB_CamCurve2, and then update the rotary cut curve by DFB_CamCurveUpdate2.
 Inputs
Name Function Data type
Setting value
(Default value)
Timing for updating
Execute
Executes the instruction to update the
cam profile.
BOOL
True/False
(False)
-
 Outputs
Name Function Data type Output range (Default value)
Done
True when the cam curve is established.
BOOL
True/False (False)
Busy
True when the instruction is executed.
BOOL
True/False (False)
Error
True if an error occurs.
BOOL
True/False (False)
ErrorID
Indicates the error code if an error occurs.
Refer to Appendices for error code
descriptions.
DWORD 0x0000, 0x3100, 0x3101, 0x3102 (0)
