Delta AH Series User Manual

Chapter 8 Memory Card
8-11
8_
(3) After you select the CPU (Need Connection) option button, you have to decide whether to include the values in the
devices in the AH Motion Controller CPU which is connected to ISPSoft.
(4) Select a backup destination. If the backup source is an ISPSoft project, the backup destination must be a computer.
a. If the Memory Card (PLC Side) button is selected, the filename of the backup file which will be produced will be
AUTOEXEC.dup, and the path which points to the backup file will be Root directory of the memory
card\AH500\SysDup\AUTOEXEC.dup.
b. If the PC (DUP File) option button is selected, you have to click
, and specify the directoty and file name for
the backup file.
