AH Motion Controller – Operation Manual
9-70
16#A004
The signal received by channel 4
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator blinks.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 4 exceeds
the range of inputs which can be received by the hardware.
16#A005
The signal received by channel 5
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator blinks.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 5 exceeds
the range of inputs which can be received by the hardware.
16#A006
The signal received by channel 6
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator blinks.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 6 exceeds
the range of inputs which can be received by the hardware.
16#A007
The signal received by channel 7
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator blinks.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 7 exceeds
the range of inputs which can be received by the hardware.
16#A400
The signal received by channel 0
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator is ON.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 0 exceeds
the range of inputs which can be received by the hardware.
16#A401
The signal received by channel 1
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator is ON.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 1 exceeds
the range of inputs which can be received by the hardware.
16#A402
The signal received by channel 2
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator is ON.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 2 exceeds
the range of inputs which can be received by the hardware.
16#A403
The signal received by channel 3
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator is ON.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 3 exceeds
the range of inputs which can be received by the hardware.
16#A404
The signal received by channel 4
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator is ON.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 4 exceeds
the range of inputs which can be received by the hardware.
16#A405
The signal received by channel 5
exceeds the range of inputs which
can be received by the hardware.
(The ERROR LED indicator is ON.)
Check the module parameter in HWCONFIG.
Check whether the signal received by channel 5 exceeds
the range of inputs which can be received by the hardware.
