AH Motion Controller – Operation Manual
4-20
(3) After the POU is added, a program editing window will appear in the main working area.
After the program editing window is opened, the corresponding toolbar will appear in the window. The functions are
described below.
Shift+Ctrl+C Displaying/Hiding the comments on the networks
None Displaying/Hiding the commands on the devices
Shift+Ctrl+A Activating/Inactivating the network selected
Shift+Ctrl+B
Adding a bookmark to the network selected or deleting a bookmark
from the network selected
Shift+Ctrl+P Going to the previous bookmarked position
Shift+Ctrl+N Going to the next bookmarked position
Ctrl+I Putting a network above the network selected
Shift+Ctrl+I Putting a network under the network selected
ESC Selection
Typing an instruction Inserting a contact
Typing an instruction Inserting a coil
Typing an instruction Inserting a comparison contact
Typing an instruction Selecting a type of comparison contact
Typing an instruction Inserting a block logic instruction (NP
/
PN
/
INV
/
FB_NP
/
FB_PN)
Typing an instruction
Selecting a type of block logic instruction
Shift+Ctrl+U Inserting an instruction or a function block
*. Please refer to section 4.5.3 for more information about typing an instruction.
Local symbol table
