AH Motion Controller – Operation Manual
9-8
_9
 Error codes and indicators
Error code Description
CPU
Status
LED indicator
status
ERROR
BUS
FAULT
16#000A
Scan timeout
(SM8: The watchdog timer error)
Stop Blinking Keep
16#000B
The program in the PLC is damaged.
Stop
ON
Keep
16#000C
The program downloaded to the PLC is incorrect.
Stop
Blinking
Keep
16#000D
The CPU parameter is damaged.
Stop
ON
Keep
16#000E
The program or the parameter is being downloaded, and therefore
the PLC can not run.
Stop Blinking Keep
16#000F
The original program in the PLC is damaged.
Continue
Keep
Keep
16#0010
The access to the memory in the CPU is denied.
Stop
ON
Keep
16#0011
The PLC ID is incorrect. (SM9)
Continue
ON
Keep
16#0012
The PLC password is incorrect.
Continue
ON
Keep
16#0013
The I/O module can not run/stop. (SM10)
Stop
Keep
ON
16#0014
The procedure of restoring the system can not be executed. (SM9)
Stop
ON
ON
16#0015
The module table is incorrect. (SM10)
Stop
ON
Keep
16#0016
The module setting is incorrect. (SM10)
Stop
ON
Keep
16#0017
The device which is associated with the data register is incorrect.
(SM10)
Stop ON Keep
16#0018
The serial port is abnormal. (SM9)
Continue
Blinking
Keep
16#0019
The USB is abnormal. (SM9)
Continue
Blinking
Keep
16#001A
The contents of the system backup file (.dup file) are incorrect.
Continue
Blinking
Keep
16#001B
Timed interrupt 0 is set incorrectly.
Stop
ON
Keep
16#001C
Timed interrupt 1 is set incorrectly.
Stop
ON
Keep
16#001D
Timed interrupt 2 is set incorrectly.
Stop
ON
Keep
16#001E
Timed interrupt 3 is set incorrectly.
Stop
ON
Keep
16#001F
The watchdog timer is set incorrectly.
Stop
ON
Keep
16#0020
The setting of the fixed scan time is incorrect.
Stop
ON
Keep
16#0021
The setting of the fixed scan time is incorrect.
Stop
ON
Keep
16#0022
The CPU parameter downloaded to the PLC is incorrect.
Stop
ON
Keep
16#0023
The Y state (STOP->RUN) section in the PLC Parameter Setting
window is set incorrectly.
Stop ON Keep
16#0024
There is no IO module on the backplane.
Continue
Keep
Keep
16#0026
The Communication Ratio box in the Communication Loading of
Scan Time (%) section in the PLC Parameter Setting window is set
incorrectly.
Stop ON Keep
16#0027
The latching auxiliary relay range which is set is incorrect.
Stop
ON
Keep
