Chapter 9 Troubleshooting
9-11
9_
Error code Description
CPU
Status
LED indicator
status
ERROR
BUS
FAULT
16#2010
1. The instruction does not support the device.
2. Encoding error
3. The instruction is a 16-bit instruction, but the constant operand is
a 32-bit code. (SM5)
Stop Blinking Keep
16#2011
The number of operands is incorrect. (SM5)
Stop
Blinking
Keep
16#2012 Incorrect division operation (SM0/SM5).
Self-define
d
Blinking Keep
16#2013
The value exceeds the range of values which can be represented
by the floating-point numbers. (SM0/SM5)
Self-define
d
Blinking Keep
16#2014
The task designated by TKON/TKOFF is incorrect, or exceeds the
range. (SM5)
Stop Blinking Keep
16#2015
There are more than 32 levels of nested program structures
supported by CALL. (SM0)
Self-define
d
Blinking Keep
16#2016
There are more than 32 levels of nested program structures
supported by FOR/NEXT. (SM0/SM5)
Self-define
d
Blinking Keep
16#2017
The number of times FOR is used is different from the number of
times NEXT is used. (SM5)
Stop Blinking Keep
16#2018
There is a label after FEND, but there is no SRET. Or there is
SRET, but there is no label. (SM5)
Stop Blinking Keep
16#2019
The interrupt task is not after FEND. (SM5)
Stop
Blinking
Keep
16#201A
IRET/SRET is not after FEND. (SM5)
Stop
Blinking
Keep
16#201B
There is an interrupt task, but there is no IRET.
There is IRET, but there is not interrupt task. (SM5)
Stop Blinking Keep
16#201C
End is not at the end of the program. (SM5)
Stop
Blinking
Keep
16#201D
There is CALL, but there is no MAR. (SM5)
Stop
Blinking
Keep
16#201E The function code used in MODRW is incorrect. (SM102/SM103)
Self-define
d
Blinking Keep
16#201F The length of the data set in MODRW is incorrect. (SM102/SM103)
Self-define
d
Blinking Keep
16#2020
The communication command received by using MODRW is
incorrect. (SM102/SM103)
Self-define
d
Blinking Keep
16#2021
The checksum of the command received by using MODRW is
incorrect. (SM102/SM103)
Self-define
d
Blinking Keep
16#2022
The format of the command used in MODRW does not conform to
the ASCII format. (SM102/SM103)
Self-define
d
Blinking Keep
16#2023
There is a communication timeout when MODRW is executed.
(SM102/SM103)
Self-define
d
Blinking Keep
16#2024
The setting value of the communication timeout is invalid when RS
is executed. (SM102/SM103)
Self-define
d
Blinking Keep
